Swan DS series professional speakers
$ -
Postage : $0.00
Model
Pro Audio DS series Professional Speaker System
Stock: 0

Product Introduction

The new generation DS Series KTV Club special speaker is specially designed for the sound reinforcement application of KTV room in large space. It includes two models: ds810 (10 inch full frequency speaker) and ds812 (12 inch full frequency speaker), which will further enrich the DS series product line.

DS series has the characteristics of transparency and easy singing, and has greatly improved its power! Thanks to the high-power design, this series of speakers still have excellent low-frequency strength and diving performance and excellent control even when inputting large dynamic signals!

DS series adopts a brand-new color scheme as a whole, with classic black as the main tone. The overall appearance is fashionable and elegant. At the same time, the surface of the front iron mesh is treated with titanium gray special process, which has brighter color and stronger corrosion and aging resistance!

Features

70°x60° coverage angle for uniform and smooth on- and off-axis response.

Crossover technology has been rigorously designed to optimize frequency response and enhance the expressiveness of mid-range vocals.

Can be used with speaker poles for vertical installation.

Sonic Guard - sound protection technology effectively protects the tweeter and avoids power overload.

The rotatable Swan luminous nameplate can be adjusted according to the installation direction.

DTF PSL passive system acousto-optic technology, perfect to enhance the product's sense of technology.

Technical Parameters

System

DS810

DS812

System type

10", 2-way, bass reflex

12", 2-way, bass reflex

Frequency Range(-10dB)1

48Hz-20kHz

45Hz-20kHz

Frequency Response(+3dB)1

80Hz-20kHz

80Hz-20kHz

Sensitivity(1w@1m)1

96dB

98dB

Rated Impedance

8Ohms

8Ohms

SPL2

122dB(continued)128dB(peak)

125dB(continued)131dB(peak)

Rated input power3

(continued/music signal/peak)

400W/800W/1600W

500W/1000W/2000W

Coverage

70°×60°(H×V)

70°×60°(H×V)

Appearance

Dimension(H×W×D)

533mm×300mm×370mm

600mm×360mm×410mm

N.W.(±10%)

16.6Kg(47.01bs)

21.3Kg(47.01bs)

Woofer

1×10"(255mm)

1×12"(304.8mm)

Tweeter

1×1.5"(38.1mm)

1×1.5"(38.1mm)

Connection

2×Neutrik®Speakon®NL4MP

2×Neutrik®Speakon®NL4MP

Structure
Trapezoid, 15mm high quality multi-layer plywood
Trapezoid, 15mm high quality multi-layer plywood



Dimensions
