HV(N) series is a new multi-functional series of professional loudspeaker system launched by Swan Group. The symmetrical cabinet design is made of high-quality sheet metal, and the exterior is coated with high-strength wear-resistant black spot paint, so that the system can be protected during transportation or installation. Using high-quality Swan electro-acoustic devices and fashionable cabinets, the sound is transparent and the dynamics are strong. The patented "X" shape molded steel mesh can effectively protect the unit and suppress harmful vibrations under high system power. All series of hanging speakers are equipped with M8 hanging points and support bases as standard, with HV12M(N) and HV15M(N) monitor speakers, which can make the system installation more diversified, facilitate engineering installation and adapt to various uses, and also It can effectively suppress the sound diffraction of the system. This system is designed for a variety of sound reinforcement applications such as entertainment venues, conferences, multi-purpose halls and live performances.

Parameters

Model

HV6(N)

HV8(N)

HV10(N)

HV12(N)

HV15(N)

HV215(N)

Frequency range

70Hz-25KHz

65Hz-25KHz

60Hz-22KHz

55Hz-22KHz

50Hz-22KHz

35Hz-21KHz

Rated power

100W

150W

250W

300W

400W

900W

Sensitvity

92dB

94dB

96dB

97dB

99dB

102dB

MAX SPL
(Peak)

118dB

122dB

126dB

128dB

131dB

138dB

Rated impedance

8Ω

8Ω

8Ω

8Ω

8Ω

4Ω

Woofer

1x6.5"(25mm voice coil)

1x8"(35mm voice coil)

1*10"(65mm voice coil)

1*12"(65mm voice coil)

1*15"(75mm voice coil)

2*15"(75mm voice coil)

Tweeter

1x25mm compressed driver

1x25mm compressed driver

1*34mm compressed driver

1*44mm compressed driver

1*44mm compressed driver

1*75mm compressed driver

Input connection

NL4(1+,1-)

NL4(1+,1-)

NL4(1+,1-)

NL4(1+,1-)

NL4(1+,1-)

NL4(1+,1-)

Coverage angle（HXV）

120°X60°

120°X60°

120°X60°

90°X50°

90°X50°

100°x50°

Cabinet finish

Environmentally friendly and wear-resistant black paint

Environmentally friendly and wear-resistant black paint

Environmentally friendly and wear-resistant black paint

Environmentally friendly and wear-resistant black paint

Environmentally friendly and wear-resistant black paint

Environmentally friendly and wear-resistant black paint

Install

M8 hoisting point, support base

M8 hoisting point, support base

M8 hoisting point, support base

M8 hoisting point, support base

M8 hoisting point, support base

M8 hoisting point

Size(mm)
(W*H*D)

215X380X240

240X415X260

300X500X320

345X580X375

430X690X450

466X1250X465

N.W.(±10%)

7.25Kg

8.25Kg

16Kg

21Kg

31Kg

59Kg

HV12M(N)

HV15M(N)

Frequency range

55Hz-22KHz

50Hz-22KHz

Rated power

300W

400W

Sensitivity

97dB

99dB

Max SPL
(Peak)

128dB

131dB

Rated impedance

8Ω

8Ω

Woofer

1*12"(65mm voice coil)

1*15"(75mm voice coil))

Tweeter

1*44mm compressed driver

1*44mm compressed driver

Input connection

NL4(1+,1-)

NL4(1+,1-)

Coverage angle HXV

90°X50°

90°X50°

Cabinet finish

Environmentally friendly and wear-resistant black paint

Environmentally friendly and wear-resistant black paint

Install

M8 lifting point

M8 lifting point

Size(mm)
(W*H*D)

580X403X496

650X445X499

N.W. (±10%)

22Kg

28Kg

Model

HV15S

HV18S

HV218S

Frequency range

40Hz-200Hz

35Hz-200Hz

30Hz-250Hz

Rated input power

450W（continual）

900W（program signal）

1800W（peak）

600W（continual）

1200W（program signal）

2400W（peak）

Sensitivity

96dB(1W/1m)

98dB(1W/1m)

102dB(1W/1m)

Max SPL

123dB（continual）

129dB（peak）

126dB（continual）

132dB（peak）

Rated impedance

8Ω

8Ω

4Ω

Woofer

1×15”(75mm voice coil)

1×18”(100mm voice coil)

2×18”(100mm voice coil)

Input connection

2×Speakon NL4

2×Speakon NL4

2×Speakon NL4

Install

floor mat

floor mat

floor mat

Dimensions (WxDxH)

476×630×610mm

556×700×695mm

1030×616×800mm

N.W.(±10%)

34.6kg

51.5kg

94kg

Product Size

Installation diagram
