Hardwares
|
|
Input channel
|
26-channel
input: 16-channel microphone: 3-channel stereo: 2-channel digital stereo (U
disk playback, USB sound card input)
|
|
Output channel
|
12-channel
output: main output L/R: 8-channel BUS output: monitor output and headphone
output L/R;
|
|
Recording interface
|
Dual
track USB sound card
|
|
Dual track U disk recording storage
|
|
Input gain
|
Mic
gain -20~+70: Line gain -20~+20
|
|
Input and output impedance
|
Mic/Line
Input: 5kΩ: Output: 200Ω
|
|
Frequency response
|
20Hz-20kHz:+/-0.5
|
|
Total Noble Distortion plus Noise THD+N
|
20dBFS@1kHz:<0.01%
|
|
Noise
|
Noise
level (20/20k bandpass): -84dBu
|
|
Dynamic Range
|
-107dB
|
|
Crosstalk
|
Isolation
between channels (+4dBu 1k): -96dB
|
|
Phase difference
|
Phase
difference between channels (+4dBu 1k) :<0.1
|
|
Equivalent noise
|
-122dB
|
|
Delay
|
<3ms
|
|
Sampling Rate
|
48k;
24bit
|
|
USB
|
Maximum
current: 500mA
|
|
Phantom power
|
+48V.
software control management
|
|
Power consumption
|
<65W
(typ.)
|
|
Power supply
|
Voltage:
100~240VAC automatic induction; AC frequency: 47~63Hz
|
|
Operating conditions
|
Temperature:-20℃-55℃
|
|
Functional indicators
|
|
DCA grouping
|
8
independently programmable DCA channels
|
|
Support all input/output channel assignment and
management
|
|
Effector
|
2
independent effect channels
|
|
8 Reverb effects: each with 7 parameters
adjustable
|
|
4 kinds of Delay delay effects: each with 5
parameters adjustable
|
|
3 Chorus effects: each with 6 parameters
adjustable
|
|
Input channel threshold
|
Threshold
Threshold:-80~0dB
|
|
Attenuation Range :-80~0dB
|
|
Ask Attack at startup: 1ms~120ms
|
|
Release time Release : 10ms~4000ms
|
|
Hold time Hold: 1ms~2000ms
|
|
Input/Output Channel Compressor
|
Threshold:
-60dB~+0dB
|
|
Compression ratio Ratio: 1:1~1000:1
|
|
Startup time Attack: 1ms~120ms
|
|
Release time Release: 10ms~4000ms
|
|
Hold time Hold: 1ms~2000ms
|
|
Makeup Gain:-20dB~+20dB
|
|
Soft inflection point controllable
|
|
Input/Output Channel Equalizer
|
4-band
parametric equalizer
|
|
Frequency of each band: 20Hz~20kHz
|
|
Q:0.05~15
|
|
Gain: -20dB~+20dB
|
|
Type optional: PEQ.HPF.LPF.HSF.LSF
|
|
Input channel filter
|
HPF:
20Hz~20kHz (-12dB/oct)
|
|
LPF: 20Hz~20kHz (-12dB/oct)
|
|
Output channel divider
|
HPF:
20Hz~20kHz, Slope: -12dB~-24dB/oct adjustable. Type:
Butterworth/Linkwitz-Riley optional
|
|
LPF: 20Hz~20kHz, Slope: -12dB~-25dB/oct
adjustable, Type: Butterworth/Linkwitz-Riley optional
|
|
31-band graphic equalizer
|
4*31
segment GEQ.20Hz~20kHz,±15dB:
|
|
2 in the main output channel, 2 can be freely
assigned to any BUS output channel
|
|
Output Channel Delay
|
Delay
time Delay: 0-735ms
|
|
Mute group
|
3
programmable mute groups
|
|
1 master effect mute group
|
|
1 total output mute group
|
