Swan CS100B Car woofer
$ 154.00
Postage : $0.00
Car Audio Car subwoofer Subwoofer
Stock:
0
More than ten years of electro-acoustic technology precipitation and classic style are integrated here-Hi-Vi CS series car subwoofer.
The CS series has launched two models, CS120B and CS100B, with unit diameters of 120mm and 100mm, respectively, to meet the low frequency requirements of different vehicle spaces. This series has made many improvements on the basis of the CS series, with more power and perfect bass performance. The vibrating cone is made of ceramic carbonized polypropylene material, which enhances the rigidity of the vibrating cone and effectively improves the unit's moisture resistance. In all kinds of harsh environments, you can sit back and relax, sit back and listen to the rumbling of the drums and let the wind and rain blow.
The long-stroke design is supplemented with special foam rubber suspension, which has better damping characteristics and effectively reduces the vibration quality of the unit, so as to obtain better low-frequency transient characteristics and sensitivity. Power tolerance and high sound pressure distortion are also extremely excellent. In addition, the high-performance magnetic circuit provides powerful power for the system. The sound is powerful, natural and flexible, giving you a super dynamic experience of car HiFi bass!
|
CS100B Professional Woofer Parameters
|
|
| Rated Impedance： | 4Ω |
| Tuning Frequency ： | 31Hz |
| Rated Impedance ： | 200W |
| Peak power： | 400W |
| Sensitivity(2.83v/1m) ： | 87dB |
| Weight ： | 3.4kg |
| Coil Diameter ： | 50mm |
| DC Resistance ： | 3.8Ω |
| Coil Width： | 27mm |
| Coil Material ： | High Temperature Resistance SV Wire |
| Coil Frame ： | High Temperature Resistance Kapton |
| Magnetic Type ： | External Magnetic |
| Magnetic material ： |
High performance ferrite |
| Force coefficient (BL value):： | 12.0N/A |
| Magnetic gap height: ： | 8.0mm |
| Maximum linear displacement: ： | 9.5mm |
| Compliance: ： | 182uM/N |
| Mechanical Q value: ： | 9.83 - |
| Electric Q value ： | 0.70 - |
| Total Q value ： | 0.65 - |
| Vibration mass ： | 141.8g |
| Equivalent volume: ： | 34.2L |
| Cabinet type: ： | Closed |
| Recommended net volume of cabinet ： | 18L |
| The cabinet is in the free field-3db frequency ： | 38Hz |
