Swan PR Series Engineering Speaker
$ -
Postage : $0.00
Model
Pro Audio PR series Professional Speaker System
Stock: 0


Product Description

PR series is a new multi-functional series of professional loudspeaker systems launched by Swan Group. The symmetrical cabinet design is made of high-quality panels, and the exterior is coated with high-strength wear-resistant black spot paint, so that the system can be effectively protected during transportation or installation. . Using high-quality Swans electro-acoustic devices and fashionable cabinets, the sound is transparent and the dynamics are powerful. The patented "X" shape molded steel mesh can effectively protect the unit and suppress harmful vibrations under high system power. All series of hanging speakers are equipped with M8 hanging points and support bases as standard, with PR3M and PR5M return speakers, which can make the system installation more diversified, facilitate engineering installation and adapt to various uses, and can also effectively suppress the system's failure. sound diffraction. This system is designed for use in casinos.

Parameters

Model

PR1

PR1+

Frequency range

70Hz-25KHz

65Hz-25KHz

Rated power

100W

150W

Sensitivity

92dB

94dB

Max SPL(peak)

118dB

122dB

Rated impedance

Woofer

1x6.5"(25mm voice coil)

1x8"(35mm voice coil)

Tweeter

1x25mm compressed driver

1x25mm compressed driver

Input connection

NL4(1+,1-)

NL4(1+,1-)

Coverage angle H×V

120°×60°

120°×60°

Cabinet finish

Environmentally friendly and wear-resistant black paint

Environmentally friendly and wear-resistant black paint

Install

M8 hoisting point, support seat

M8 hoisting point, support seat

Size(mm)(W*H*D)

215×380×240

240×415×260

N.W.(±10%)

7.25Kg

8.25Kg


Model PR2 PR3 PR5 PR52
Frequency range 60Hz-20KHz 55Hz-22KHz 50Hz-22KHz 35Hz-21KHz
Rated power 250W 300W 400W 900W
Sensitivity 96dB 97dB 99dB 102dB
MAX SPL(peak) 126dB 128dB 131dB 138dB
Rated impedance
Woofer 1*10"(65mm voice coil) 1*12"(65mm voice coil) 1*15*(75mm voice coil) 2*15*(75mm voice coil)
Tweeter 1*34mm compressed driver 1*44mm compressed driver 1*44mm compressed driver 1*75mm compressed driver
Input connection NL4(1+,1-) NL4(1+,1-) NL4(1+,1) NL4(1+,1-)
Coverage angle HXV 120°X60° 90°×50° 90°×50° 100°×50°
Cabinet finish Environmentally friendly and wear-resistant black paint Environmentally friendly and wear-resistant black paint Environmentally friendly and wear-resistant black paint Environmentally friendly and wear-resistant black paint
Install M8 hoisting point, support seat M8 hoisting point, support seat M8 hoisting point, support seat M8 hoisting point
Size(mm)(W*H*D) 300X500X320 345X580X375 430X690X450 466X1250X465
N.W.(±10%) 16Kg 21Kg 31Kg 59Kg


Model        PR3M PR5M
Frequency range 55Hz-22KHz 50Hz-22KHz
Rated power 300W 400W
Sensitivity 97dB 99dB
MAX SPL(peak) 128dB 131dB
Rated impedance
Woofer 1*12"(65mm voice coil) 1*15"(75mm voice coil)
Tweeter 1*44mm compressed driver 1*44mm compressed driver
Input connection NL4(1+,1-) NL4(1+,1-)
Coverage angel HXV 90°X50° 90°X50°
Cabinet finish Environmentally friendly and wear-resistant black paint Environmentally friendly and wear-resistant black paint
Install M8 hanging M8 hanging
Size(mm)(W*H*D) 580X403X496 650X445X499
N.W.  22kg  28kg

Size and Structure



Install Demonstration
