Swan T6/T8 Series Line Array Speaker
$ -
Postage : $0.00
Pro Audio Line array T6/T8 series line array speaker
Stock:
0
T6 and T8 series are the latest professional vertical line array sound reinforcement systems in hivi, designed for professional sound reinforcement occasions such as conference rooms, multi-function halls, auditoriums and small and medium-sized mobile Shang Yan. Through the correction of the wave front and the special ring-shaped patent hanging device, the same series of speakers can be conveniently and flexibly assembled to form a good array line sound source amplification. With the built-in frequency division network optimized by professional electroacoustic technology, the continuous sound pressure level is high, the dynamic state is large and the transient state is good. Both series can support a variety of combination forms, and can be expanded with ultra-low frequency speakers to form a powerful professional line array sound amplification system with natural division of near, middle and far fields.
|
|
||||
|
Parameters |
||||
|
Speaker model |
T6A |
T6B |
T8A |
T8B |
|
Model name |
Line array full range speaker |
Line array full range speaker |
Line array full range speaker |
Line array full range speaker |
|
Frequency range |
75Hz-22KHz |
75Hz-22KHz |
70Hz-22KHz |
70Hz-22KHz |
|
Rated input power |
400W |
400W |
500W |
500W |
|
Sensitivity |
99dB |
99dB |
100dB |
100dB |
|
Max SPL |
131dB |
131dB |
133dB |
133dB |
|
Impedance |
16Ω |
16Ω |
16Ω |
16Ω |
|
Coverage angle(H×V) |
100×15° |
100×15° |
100×15° |
100×15° |
|
Woofer |
2×6.5"(38mm) |
2×6.5"(38mm) |
2×8"(50mm) |
2×8"(50mm) |
| Tweeter |
1×44mm(Neodymium magnetism) |
1×44mm(Neodymium magnetism) |
1×44mm(Neodymium magnetism) |
1×44mm(Neodymium magnetism) |
|
Input connection |
2×NL4 士1 |
2×NL4 士1 |
2×NL4 ±1 |
2×NL4 ±1 |
|
Install |
Wall hanging, ring hanging pieces, Top hanging and supporting |
Wall hanging, ring hanging pieces, Top hanging and supporting |
Wall hanging, ring hanging pieces, Top hanging and supporting |
Wall hanging, ring hanging pieces, Top hanging and supporting |
|
Size (H×W×D) |
620×199×240mm |
620×199×240mm |
680×245×270mm |
680×245×270mm |
|
N.W.(±10%) |
13.5Kg |
12Kg |
17Kg |
14.5K |
|
Product installation diagram |
||||
|
|
||||
|
Size and dimension |
||||
|
|
||||
