Design Features:
Leading Small/Thiele parameter optimization design technology-convenient cabinet design! German imported paper and fiber mixed material diaphragm, surface marble treatment-natural and accurate sound, German fatigue-resistant high-loss natural rubber folding ring-strong absorption of excess vibration energy, High permeability and high stability linear centering support piece-improve the air compression characteristics, single magnet high performance large magnetic circuit system-dynamic linear drive source, Hivi's symmetrical magnetic field (SMD) drive technology-high sound pressure distortion Output, finite element precision computer simulation design, integrated high-density aluminum frame-to prevent harmful resonance, high-power high temperature resistance and no eddy current loss AL voice coil frame-guarantee of high-quality bass.
Voice characteristics:
Naturally accurate, highly analytical, full of vitality and dynamic!
It is suitable for the low frequency unit in the Hi-Fi two-way phase inverted speaker system and the midrange unit in the three-way system.
|
Swan C8 Parameter
|
|||
| Parameters | Mark | Value | Unit |
| Basic application parameters | |||
| Rated impedance | Z | 8 | Ω |
| Resonant frequency | Fs | 35 | Hz |
| Rated power | Pnom | 80 | w |
| Maximum power | Pmax | 160 | w |
| Sensitivity (2.83V/1m) | E | 89 | dB |
| Weight | w | 2.3 | kg |
| Voice coil | |||
| Voice coil diameter | ∅ | 35 | mm |
| DC Resistance | Re | 7.2 | Ω |
| Voice coil width | H | 17.8 | mm |
| Voice coil wire | High temperature SV wire | ||
| Voice coil bobbin | AL | ||
| Circuit | |||
| Magnetic circuit type | Single magnetic large magnetic circuit | ||
| Magnet material | High Performance Ferrite | ||
| Force coefficient (BL value) | BL | 9.8 | N/A |
| Magnetic gap height | He | 6 | mm |
| Maximum Linear Displacement | Xmax | 5.9 | mm |
| Small/ Thiele Parameters | |||
| Consistency | Cms | 824 | uM/N |
| Mechanical Q | Qms | 2.69 | - |
| Electric Q value | Qes | 0.42 | - |
| Total Q | Qts | 0.36 | - |
| Vibration mass | Mms | 24.9 | g |
| Equivalent volume | Vas | 56.1 | L |
| Recommended cabinet parameters | |||
| Cabinet type | Phase Inverted | ||
| Recommended net volume of box | Vb | 28.5 | L |
| Inverter tuning frequency | Fb | 33 | Hz |
| Cabinet at -3dB frequency in free field | F3 | 36 | Hz |
|
Swan C8 Parameter
|
|||
| Parameters | Mark | Value | Unit |
| Basic application parameters | |||
| Rated impedance | Z | 8 | Ω |
| Resonant frequency | Fs | 35 | Hz |
| Rated power | Pnom | 80 | w |
| Maximum power | Pmax | 160 | w |
| Sensitivity (2.83V/1m) | E | 89 | dB |
| Weight | w | 2.3 | kg |
| Voice coil | |||
| Voice coil diameter | ∅ | 35 | mm |
| DC Resistance | Re | 7.2 | Ω |
| Voice coil width | H | 17.8 | mm |
| Voice coil wire | High temperature SV wire | ||
| Voice coil bobbin | AL | ||
| Circuit | |||
| Magnetic circuit type | Single magnetic large magnetic circuit | ||
| Magnet material | High Performance Ferrite | ||
| Force coefficient (BL value) | BL | 9.8 | N/A |
| Magnetic gap height | He | 6 | mm |
| Maximum Linear Displacement | Xmax | 5.9 | mm |
| Small/ Thiele Parameters | |||
| Consistency | Cms | 824 | uM/N |
| Mechanical Q | Qms | 2.69 | - |
| Electric Q value | Qes | 0.42 | - |
| Total Q | Qts | 0.36 | - |
| Vibration mass | Mms | 24.9 | g |
| Equivalent volume | Vas | 56.1 | L |
| Recommended cabinet parameters | |||
| Cabinet type | Phase Inverted | ||
| Recommended net volume of box | Vb | 28.5 | L |
| Inverter tuning frequency | Fb | 33 | Hz |
| Cabinet at -3dB frequency in free field | F3 | 36 | Hz |
