Product Description |
||||||
MK series speakers are the latest "KTV" multi-function speaker system developed by Swan, which combines professional KTV and multi-channel cinema effects. In addition to being used in entertainment venues such as professional movie karaoke bars and KTV private rooms, the box design of the original wood grain color is also suitable for the needs of high-end home movie karaoke sound. The speaker adopts Swan professional horn tweeter with professional mid-bass, with built-in professional electro-acoustic technology optimized crossover network, the sound is clear and dynamic. |
||||||
Product Parameters |
||||||
Model |
MK06R |
MK08R |
MK10F |
MK12F |
MK26C |
MK12S |
Frequency Range |
80Hz-20KHZ |
70Hz-20KHZ |
60Hz-20KHz |
50Hz-20KHz |
70Hz-20KHz |
30Hz-350HZ |
Sensitivity | 94dB | 96dB | 97dB | 98dB | 97dB | 96dB |
SPL |
continued :115dB
peak :121dB
|
continued :118dB
peak :124dB
|
continued :124dB
peak :127dB
|
continued :123dB
peak :129dB
|
continued :121dB
peak :127dB
|
continued :122dB
peak :128dB
|
Input Power |
continued :120W
program signal :240W
peak :480W
|
continued :150W
program signal :300W
peak :600W
|
continued :300W
program signal :500W
peak :1000W
|
continued :300W
program signal :600W
peak :1200W
|
continued :250W
program signal :500W
peak :1000W
|
continued :400W
program signal :800W
peak :1600W
|
Rated Impedance | 8Ω | 8Ω | 8Ω | 8Ω | 8Ω | 8Ω |
Coverage | 90×50 | 90×50 | 90×50 | 90×50 | 90×50 | full-direction |
Woofer | 1x6.5"(38mm) | 1x8"(50mm) | 1×10”(65mm) | 1×12”(65mm) | 2x6.5"(38mm) | 1×12”(75mm) |
Tweeter | 1×44mm compressed drive | 1×44mm compressed drive | 1×44mm compressed drive | 1×44mm compressed drive | 1×44mm compressed drive | None |
Dimension (W×H×D) |
257×367×186 | 277×429×218 |
350x450x277 |
394×562×303 |
660x212x230mm |
450×550×434 |
N.W.(±10%) | 8.4kg | 9kg |
14 Kg |
17.6kg | 13.3kg | 22kg |
Product Dimension | ||||||
![]() |
