WRM (MR) series is a professional two-way coaxial stage return full-range speaker, designed for professional stage return, monitoring and other sound reinforcement occasions. Using high-quality Swans electro-acoustic devices and special cabinet design, it can form a more ideal sound field environment.

WRM series adopts waterproof paint surface, which can be suitable for outdoor harsh weather; MR series adopts ordinary paint surface.

Product Parameter

Model

WRM1(MR1）

WRM2(MR2)

Frequency

55Hz-20KHz

50Hz-20KHz

Rated input power

500W（Continued）

1000W（Program signal）

2000W（Peak）

600W（Continued）

1200W（Program signal）

2400W（Peak）

Sensitivity

99dB（1W/1m）

101dB（1W/1m）

SPL

126dB（Continued）

132dB（Peak）

129dB（Continued）

135dB（Peak）

Rated impedance

8Ω

8Ω

Coverage（H×V）

60°×60°

60°×60°

Woofer

12”（75mm）Nd

15”（75mm）Nd

Tweeter

1×65mm Diaphragm Nd tweeter

1×75mm Diaphragm Nd tweeter

Connection

2×7Pin waterproof(1+,2-),(2×NL4)

2×7Pin  waterproof(1+,2-),(2×NL4)

Installation

Foot pads，Ring，suspension buckle

Foot pads，Ring，suspension buckle

Dimension（W×H×D）

536×410×480mm

620×438×519mm

N.W.(±10%)

23KG

26.5KG

Installation Instructions

Product Dimension
