Swan WK Cinema KTV Series
$ -
Postage : $0.00
Home Theather Cinema Karaoke Series
| WK Cinema KTV Series Parameters | |||
| Speaker model | WK06R | WK08R | WK26C |
| Frequency Range | 80Hz-20KHz | 70Hz-20KHz | 70Hz-20KHz |
| Rated input power | 120W (continuous) | 150W (continuous) | 250W (continuous) |
| 240W (program signal) | 300W (program signal) | 500W (program signal) | |
| 480W (peak) | 600W (peak) | 1000W (peak) | |
| Sensitivity | 94dB(1W/1m) | 96dB(1W/1m) | 97dB(1W/1m) |
| Maximum sound pressure level | 115dB(Continuous) | 118dB(Continuous) | 121dB(Continuous) |
| /121dB(peak) | /124dB(peak) | /127dB(peak) | |
| Rated impedance | 8Ω | 8Ω | 8Ω |
| Covering angle (H×V) | 90 degrees × 50 degrees | 90 degrees × 50 degrees | 90 degrees × 50 degrees |
| Woofer | 1×6.5"(38mm voice coil) | 1×8"(50mm voice coil) | 2×6.5"(38mm voice coil) |
| Tweeter | 1 x 44mm compression driver | 1 x 44mm compression driver | 1 x 44mm compression driver |
| Input connection | 2P button | 2P button | 2P button copper column |
| Install | M8 lifting point / special pendant | M8 lifting point / special pendant | M8 lifting point / special pendant |
| Dimensions (W×H×D) | 257×367×186mm | 277×429×218mm | 660×212×230mm |
| Net weight | 8.4Kg | 9Kg | 13.5Kg |
| Speaker model | WK10F | WK12F | WK12S |
| Frequency Range | 60Hz-20KHz | 50Hz-20KHz | 30Hz-350KHz |
| Rated input power | 250W (continuous) | 300W (continuous) | 400W (continuous) |
| 500W (program signal) | 600W (program signal) | 800W (program signal) | |
| 1000W (peak) | 1200W (peak) | 1600W (peak) | |
| Sensitivity | 97dB(1W/1m) | 98dB(1W/1m) | 96dB(1W/1m) |
| Maximum sound pressure level | 121dB(Continuous) | 123dB(Continuous) | 122dB(Continuous) |
| /127dB(peak) | /129dB(peak) | /128dB(peak) | |
| Rated impedance | 8Ω | 8Ω | 8Ω |
| Covering angle (H×V) | 90 degrees × 50 degrees | 90 degrees × 50 degrees | omnidirectional |
| Woofer | 1×10"(65mm voice coil) | 1×12"(65mm voice coil) | 1×12"(75mm voice coil) |
| Tweeter | 1 x 44mm compression driver | 1 x 44mm compression driver | |
| Input connection | 2P button copper column | 2P button copper column | 2P button copper column |
| Install | M8 lifting point / special pendant | M8 lifting point / special pendant | floor mat |
| Dimensions (W×H×D) | 350×450×277mm | 394×562×303mm | 450×550×434mm |
| Net weight | 14Kg | 17.6Kg | 22Kg |
