●Humanized design, easy to install and easy to use.
●Flat frequency response curve, transparent and natural sound performance, good balance.
●Special damping glue treatment, high music resolution, wider and even coverage.
●The all-aluminum alloy surface net will never rust and provide excellent reliability.
●Narrow frame design, which can integrate superior and decoration styles, which is more in line with modern architectural design.

Product use:
1. Applicable to various public places such as supermarkets, shopping malls, waiting rooms, hotels, etc.
2. It is suitable for building an in-wall home theater system that is completely integrated with the home.
3. Suitable for small multi-room meetings, offices, business and other places.
  Product Specifications:
| Model | TQ106A | TQ109A |
| Speaker Diameter | 5.25"X1 | 8"X1 2"X1 |
| Rated power | 10W | 30W |
| *Power | 20W | 60W |
| Input voltage | 70V/100V | 70V/100V |
| Sensitivity | 92dB | 92dB |
| Frequency range | 200Hz-18KHz | 140Hz-18KHz |
| *Large sound pressure level | 102dB | 106dB |
| Weight(kg) | 1.3 | 3 |
| Hole dimension(mm) | Φ177 | Φ225 |
